Cisco UCS-CPU-I6246R Product Introduction The Cisco UCS-CPU-I6246R is a high-performance processor designed for enterprise data centers, featuring the Intel 6246R 3.4GHz/205W with 16 cores and 35.75MB cache. It's ideal for organizations requiring robust processing power for demanding applications, such as virtualization and database management, delivering exceptional performance with DDR4 2933MHz support.
Cisco UCS-CPU-I6246R Product Highlights - ● 3.4GHz clock speed
- ● 205 watt TDP
- ● 16-core CPU
- ● 35.75MB cache
- ● 2933MHz DDR4 support
Product Features Comparison Model | Clock Speed | Power Consumption | Core Count | Cache Size | Memory Type |
Cisco UCS-CPU-I6246R | 3.4GHz | 205W | 16-core | 35.75MB | DDR4 2933MHz |
Intel Xeon Gold 6242 | 2.8GHz | 150W | 16-core | 22MB | DDR4 2933MHz |
Intel Xeon Gold 6230R | 2.1GHz | 125W | 26-core | 35.75MB | DDR4 2933MHz |
Intel Xeon Gold 6258R | 2.7GHz | 205W | 28-core | 38.5MB | DDR4 2933MHz |
Intel Xeon Gold 6226R | 2.9GHz | 150W | 16-core | 22MB | DDR4 2933MHz |
Cisco UCS-CPU-I6246R Product Application Scenarios - ● High-performance computing
- ● Virtualized environments
- ● Database management systems
Optional Add-ons Model | Description |
Cisco UCS-MR-X32G2RT | 32GB DDR4 2933MHz memory module |
Cisco UCSC-SD960G12S3-EP | 960GB Enterprise Performance SSD |
Cisco UCSC-PSU2V2-1400W | 1400W AC Power Supply |
Get More Information Discover unbeatable prices and fast shipping for the Cisco UCS-CPU-I6246R. Access the detailed UCS-CPU-I6246R datasheet and ensure you're getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at sales@router-switch.com.
Brand
Cisco
Cache
35.75 MB
Clock Speed
3.4 GHz
Enhanced Intel SpeedStep Technology
Yes
Instruction Set
64-bit
Intel Hyper-Threading Technology
Yes
Intel Optane Memory Supported
Yes
Intel Turbo Boost Technology
2.0
Manufacturing Process
14 nm
Max Turbo Frequency
4.0 GHz
Maximum Number of PCI Express Lanes
48
Memory Speed
2933MHz
Memory Type
DDR4
Model Number
UCS-CPU-I6246R
Number of Cores
16
Power Consumption
205W
Processor
Intel Xeon Gold 6246R
Scalability
S4S
Socket Supported
LGA 3647
Thermal Design Power (TDP)
205 watts
