Additional Features
Support for multicast, QoS, and security features
Application Scenario
FTTH, FTTO, FTTB
Brand
Huawei
Compatible Equipment
SmartAX MA5800 Series
Data Rate
Up to 10 Gbps per port
GPON Features
Class B+ and Class C+ optical modules
Hot Swappable
Yes
Installation Mode
Plug and play installation in SmartAX MA5800 Series frame
Interface Board Type
8-port XG-PON and GPON Combo OLT
Model Name
SmartAX MA5800 H901CGID
Network Management
SNMP, Telnet, OMCI
ONT Compatibility
Fully compatible with Huawei ONT
Operational Humidity
5% to 95% (non-condensing)
Operational Temperature
-10°C to 55°C
Physical Dimensions
Specified for SmartAX MA5800 Series chassis
Port Quantity
8 Ports
Power Consumption
Low power consumption design
Reliability
High reliability and stability
Technology
XG-PON and GPON
Transmission Distance
Up to 20 km
Uplink Interface
SFP+
Wavelengths
Downstream: 1490nm, Upstream: 1310nm (GPON); 1577nm/1270nm (XG-PON)
