Brand
Kingston
Capacity
480GB, 960GB, 1.92TB, 3.84TB, 7.68TB
Dimension (L x W x H)
100.00mm x 69.85mm x 7.00mm
Endurance (TBW)
Up to 1.3PBW
Form Factor
2.5-inch
Interface
SATA III (6Gbps)
Model
SEDC500R
MTBF
2 million hours
NAND Type
3D TLC
Operating Temperature
0°C to 70°C
Power Consumption (Active)
6.6W (read), 9.3W (write)
Power Consumption (Idle)
1.3W
Random 4K Read Speed
Up to 98,000 IOPS
Random 4K Write Speed
Up to 28,000 IOPS
Read Latency
~110 °s
Sequential Read Speed
Up to 550MB/s
Sequential Write Speed
Up to 520MB/s
Shock Resistance
1500G
Storage Temperature
-40°C to 85°C
Vibration Operating
2.17G (7-800 Hz)
Write Latency
~30 °s
