Antenna Type
Omni-directional
Application
Indoor Wi-Fi coverage and connectivity
Brand
Aruba
Compatibility
Compatible with select Aruba Access Points
Compliance
RoHS, WEEE
Connector Type
RP-SMA
Dimensions (H x W x D)
Specific dimensions not provided
Frequency Range
2.4 GHz & 5 GHz
Gain
2.5 dBi (2.4 GHz) / 6 dBi (5 GHz)
Horizontal Beamwidth
360 degrees
Impedance
50 Ohms
Included Accessories
Mounting brackets
Model
JG696A
Mounting
Indoor Mounting
Number of Elements
4
Operational Temperature
-20°C to +55°C
Polarization
Linear
Product Name
HP Indoor Omni 2.5/6dBi MIMO 4 Element Antenna
Vertical Beamwidth
40 degrees (2.4 GHz) / 30 degrees (5 GHz)
Warranty
Limited Lifetime Warranty
