Brand
HPE
Dimensions (HxWxD)
4.28 x 17.11 x 15.05 in (10.88 x 43.46 x 38.21 cm)
Documentation
QuickSpecs, User Guide, and Integrated Management Display (IMD) Quick Start Guide
Environment
Energy Star certified
Expansion Slots
2 PCIe slots (x8, half-height, half-length)
Form Factor
1U Rack Mount
Hard Drive
2 Large Form Factor (LFF) Non-Hot Plug Drive Bays
Management
HPE iLO 5, HPE iLO Standard with Intelligent Provisioning
Memory
16GB (1x16GB) RDIMM, 2666 MT/s, Dual Rank
Model
HPE DL20 Gen10+ 2LFF CTO Svr 2314/16GB /290W/
Networking
Embedded Broadcom 5720 Dual-port 1GbE Adapter
Operating System
No Operating System included
Power Supply
290W Non-hot plug, Non-redundant Power Supply
Processor
Intel Xeon E-2314 (4 core, 3.8 GHz, 8MB, 71W)
Security
UEFI Secure Boot and Secure Start support
Storage Controller
HPE Smart Array S100i Software RAID
USB Ports
4 USB 3.2 Gen 1 (2 front, 2 rear) and 2 USB 2.0 (rear)
Warranty
3-year parts, 1-year labor, and 1-year onsite support
Weight
Not Applicable
