Brand
Mellanox
Console Ports
1x USB, 1x Serial
Data Rate Per Port
200GbE
Dimensions (HxWxD)
1.72" x 16.85" x 24"
Forwarding Capacity
12.8Tb/s
LED Indicators
Per port and system status
MAC Entries
1M
Management Interface
1x RJ-45
Maximum Latency
300ns
Model
MT53132-NCCR-V
Operating Temperature
0°C to 45°C
Packet Buffer
42MB
PAM4 Modulation
128x50Gb/s
Port Configuration
32 Ports
Power Consumption
400W
Quality of Service (QoS)
8 priority queues
Redundancy
Hot-swappable power supplies and fans
Regulatory Compliance
FCC, CE, UL, RoHS
Relative Humidity
5% to 95% (non-condensing)
Security Features
ACLs, CoPP, DDoS protection
Storage Temperature
-40°C to 70°C
Switch Family
Spectrum-2
VLAN Support
4K VLAN IDs
