TOM1000-C12U4080
TOM1000-C12U4080
TOM1000-C12U4080
TOM1000-C12U4080
TOM1000-C12U4080
TOM1000-C12U4080

TOM1000-C12U4080

Нет отзывов
Код товара: MRD TOM1000-C12U4080
0 ₽
В наличии много 1000 шт

TOM1000 Layer2+ Industrial Switch made from Anti-Corrosion Casting Alu-minum Alloy. 4 2500 BaseX SFP Ports (SFP module not included), 8 10/100/1000BaseT Ports. 1 Management Serial CLI Port, IP40 Protection Class, Operating Temperature from -40°C to +75°C, and MTBF over 400K hours. Isolated Dual Universal Power Inputs (18~300VDC or 90~264VAC ). CLI and Power Cable Order Separately.

Quick Spec

Table 1 shows the quick spec of the TOM1000-C12U4080

Model TOM1000-C12U4080
Interface Configuration 4 x 100/1000/2500BaseX SFP Ports
8 x 10/100/1000BaseT Ports
Input Voltage 18~300VDC or 90~264VAC
Fansless Yes
Backplane Bandwidth 68 Gbps
Installasion DIN-Rail
IP Rating IP30;
Conformal Coated Optional
Dimensions (W x H x D) 52mm x 140mm x 110mm
2.05 inch x 5.51 inch x 4.34inch
Weight 0.7 kg
1.54 lb
MTBF ≥400,000H
Operating Temperature -40 °C~ 85 °C
-40°F ~ 185°F
Product Safety CE.CB.IEC.IECEE
IEC/EN62368-1
FCC Part 15 Subpart B Class A
Hazardous Area UL/cUL1604 Class 1 Div 2 (pending)
Transportaon Industry JT/T817-2011; NEMA-TS2 (pending)
Rail Industry EN50121-4
Power Industry IEC61850-3
IEEE1613 (C37.90.x)
Industrial Control Industry UL/cUL61010 (pending)
Shipbuilding Industry GL (pending)

Product Features

● Easy network management by web browser, CLI, Telnet, serial console
● IGMP snooping and GRMP for filtering multicast traffic
● Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network planning
● QoS (IEEE 802.1P/1Q and TOS/DiffServ) to increase determinism
● SNMPv1/v2c/v3 for different levels of network management
● Support IEEE 802.3af/at compliant PoE
● Each PoE port provides up to 30W output power
● PoE management: PoE device detection, PoE power management
● Dual redundant power inputs design for DC models
● Die-casting aluminum alloy housing
● Fanless, -40 to 75°C wide operating temperature range
● MTBF≥400, 000H

Supported Options

Table 2 shows the supported options of the TOM1000-C12U4080

MRD-MGIGA-GLX Industrial Grade 1000BaseX SFP Module, Singlemode(1310), Dual Fibers, DDM, 20KM
MRD-MGIGA-GEX Industrial Grade 1000BaseX SFP Module, Singlemode(1310), Dual Fibers, DDM, 40KM
MRD-MGIGA-GZX Industrial Grade 1000BaseX SFP Module, Singlemode(1550), Dual Fibers, DDM, 80KM
MRD-MGIGA-GSX-850 Industrial Grade 1000BaseX SFP Module, Multimode(850), Dual Fibers, DDM, 550M
MRD-MGIGA-GSX Industrial Grade 1000BaseX SFP Module, Multimode(1310), Dual Fibers, DDM, 2KM

Compare to Similar Items

Table 3 shows the comparison to similar items of the TOM1000-C12U4080

Product number Product description
EDS-G512E-4GSFP-T 8 x GE + 4 x GX SFP (MOXA)
EDS-G4014-6QGS-LV-T 8 x GE + 4 x 2.5G SFP (MOXA)

Get More Information

Do you have any questions about the TOM1000-C12U4080 price?

Contact us now via Live Chat or sales@router-switch.com.

Характеристики

Ambient Relative Humidity 5 % ~ 95% (non-condensing)
Backplane Bandwidth 68 Gbps
Circuit Board Approved by IPC
Conformal Coated Optional
Connection 1 removable 5-contact terminal block
Diagnosis Mode Indicator light, journal file, relay, RMON, port mirroring, TRAP
Dimensions (W x H x D) 52mm x 140mm x 110mm
EMI FCC 47 CFR Part 15 Class A EN55022 Class A
EMS IEC (EN )61000-4-2, Class 4IEC (EN )61000-4-3, Class 3IEC (EN )61000-4-4, Class 4IEC (EN )61000-4-5, Class 4IEC (EN )61000-4-6, Class 3IEC (EN )61000-4-8, Class 5
Exchange Rate 148,800 pps/100M; 1,488,000 pps/1000 M;
Freefall IEC 60068-2-31
Hazardous Area UL/cUL1604 Class 1 Div 2 (pending)
Housing Aluminum Alloy Housing
Industrial Control Industry UL/cUL61010(pending)
Input Voltage 18~300VDC or 90~264VAC
Installasion DIN-Rail
IP Rating IP40;
MAC Table Size 16K
Management Mode Browser, Serial Port, STD-17 MIB-II, STD-58 SMIv2, STD-59 RMON, STD-62SNMPv3, SNMPv2c, SNMPv1, RFC2925 Ping MIB, MRD Private MIBs
MTBF ≥400,000H
Operating Temperature -40 ℃ ~ 85 ℃
Others 4K VLANS, IPv4/IPv6 multicast, storm control, MC/BC Protection, support Jumbo Frame
Overload Current Protection Supported
Packet Buffer Size 4Mbti
Power Consumption 10W（without POE）
Power Industry IEC61850-3 IEEE1613 (C37.90.x)
Processing Type Store-and-Forward
Product Safety CE.CB.IEC.IECEEIEC/EN62368-1FCC Part 15 Subpart B Class A
Rail Industry EN50155; IEC/EN61373; EN50121
Redundancy RSTP, STP, MRD-Ring® , port trunking
Reverse Polarity Protection Supported
Shipbuilding Industry DNV-GL (pending)
Shock IEC 60068-2-27
Storage Temperature -40 ℃ ~ 85 ℃
Time Synchronization SNTP
Transportaon Industry JT/T817-2011(pending)
Vibration IEC 60068-2-6
Weight 0.7 kg
