Brand
Juniper
Chassis Compatibility
EX9200 Series
Dimensions
1.75 x 18.3 x 17.0 inches
Environment
Operating Temperature: 0??C to 40??C
Forwarding Capacity
Up to 1.08 Bpps
Jumbo Frame Support
Yes, up to 9,216 bytes
Layer
Layer 2 and Layer 3
MAC Address Table Size
160,000 entries
Management Interface
CLI, J-Web, Junos Space
Maximum Power Consumption
500 Watts
Model
EX9200-32XS
MTBF (Mean Time Between Failures)
Up to 320,000 hours
Optics
Requires SFP+ optics sold separately
Port Count
32
Port Type
10GbE SFP+
Power Supplies
AC and DC options
Quality of Service (QoS)
Supported
Redundancy
Hot-swappable Redundant Components
Routing Protocols
OSPF, BGP, RIP, IS-IS
Supported Optics
SFP+ (10GbE)
Switching Capacity
Up to 1.44 Tbps
