Brand
HPE
Device Type
Switch - 48 ports - Managed - Stackable
Dimensions (H x W x D)
1.73 x 17.32 x 18.98 in (44 x 440 x 482 mm)
Fan Tray
2 (1+1 redundancy)
Latency
1 °s 10/25 GbE Latency
Layer Supported
2 to 3
Management Features
SNMP, RMON, sFlow, OpenFlow (SDN)
Memory and Processor
2 GB SDRAM, Dual Core ARM Coretex A9 @ 1016 MHz, 16 GB flash
Model Number
JH391A
Mounting
Rack mountable
Operating Relative Humidity
10% to 90%, non-condensing
Operating Temperature
0°C to 45°C
Performance
Up to 1.44 Tbps switching capacity
Ports
48 x 1/10/25Gb Ethernet Fixed 1000/10000 SFP+ Ports, 6 x 40/100Gb QSFP28 Ports
Power Consumption
Typical: 350W, Maximum: 420W
Power Supply
2 power supply slots
Product Name
HPE FlexFabric 5940 48XGT 6QSFP28 Switch
Quality of Service (QoS)
Advanced QoS features with IPv4/IPv6 Layer 3 services
Security Features
ACLs, DHCP snooping, DoS attack prevention
Throughput
Up to 1071 Mpps
VLAN Support
Yes
Warranty
Limited Lifetime Warranty
