Brand
HPE
Flash Memory
512 MB
Form Factor
1U Rack Mountable
Layer Supported
3
MAC Address Table Size
128K entries
Management
SNMP 1, RMON 2, RMON, SNMP 3, SNMP 2c, HTTP, CLI
Memory
2 GB
Model Number
JG336A
Operating Humidity Range
10% to 90%, non-condensing
Operating Temperature Range
0°C to 45°C
Packet Buffer Size
9 MB
Ports
48 x 10GbE SFP+ and 4 x 40GbE QSFP+
Power Consumption
Typical: 270W, Maximum: 450W
Power Supply
Dual, Hot-plug, Redundant Power Supplies (optional)
Product Name
HPE 5900AF-48XGT-4QSFP+ Switch
Quality of Service (QoS)
Advanced QoS with support for IPv4/IPv6, flows, port mirroring, and VLANs
Security Features
ACLs, RADIUS, TACACS+, SSL, SSH, Secure FTP
Storage Humidity Range
5% to 95%, non-condensing
Storage Temperature Range
-40°C to 70°C
Switching Capacity
Up to 960 Mpps
Throughput
Up to 1.44 Tbps
VLAN Support
Yes, up to 4096 VLAN IDs
