Brand
HPE
Compliance Standards
IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), and more
Device Type
Switch - 48 ports - L3 - Managed
Dimensions (WxDxH)
17.32 x 26 x 1.72 in
Environmental Parameters
Operating temperature: 32 to 113 F, Storage temperature: -40 to 158 F
Flash Memory
512 MB
Form Factor
Rack-mountable 1U
Jumbo Frame Support
Yes, up to 9,216 bytes
MAC Address Table Size
128K entries
Management
SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTPS, TFTP, SSH-2
Performance
Throughput up to 1.44 Tbps, Switching capacity 960 Gbps
Ports
48 x 10 Gigabit SFP+ / 4 x 40 Gigabit QSFP+
Power
AC 120/230 V (50/60 Hz)
Power Redundancy
Optional
Product Model
JC772A
Product Name
5900AF-48XG-4QSFP+ Switch
RAM
2 GB
Routing Protocol
OSPF, RIP, BGP-4, IS-IS, IGMP, VRRP, PIM-SM, static IP routing, ECMP
Security Features
ACLs, RADIUS, Secure Shell v2 (SSHv2), SNMPv3, and more
Virtualization Technology
HP IRF Technology
Warranty
Limited lifetime warranty
