Brand
HPE
Compliant Standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1ab (LLDP)
Device Type
Switch - 24 ports - Managed
Dimensions (WxDxH)
17.32 x 16.54 x 1.72 in
Enclosure Type
Rack-mountable 1U
Features
VLAN support, Syslog support, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, IPv6 support
Humidity Range Operating
10-90% (non-condensing)
Jumbo Frame Support
Yes
MAC Address Table Size
32K entries
Management
SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTPS, TFTP
Networking Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Networking Type
Switch
Performance
480 Gbps switching capacity
Ports
24 x 10G SFP+
Power Supply
Two power supply units required (sold separately)
Product Model
JC103B
Product Name
FlexFabric 5820X 24XG SFP+ Switch
Routing Protocol
Static IPv4/IPv6 routing, RIP, OSPF, BGP, IS-IS
Temperature Range Operating
32°F to 113°F (0°C to 45°C)
Throughput
Up to 357.14 Mpps
Warranty
Limited lifetime warranty
