Compliance
CE, FCC, RoHS
Dimensions (WxDxH)
440 x 420 x 44 mm
Expansion Slots
4 x Interface Module Slots
Forwarding Rate
Up to 357.14 Mpps
IPv4 Routes
Up to 64K
IPv6 Routes
Up to 32K
Layer 3 Features
Static Routing, RIP, OSPF, BGP, IS-IS
MAC Address Table
128K
Management
Web-based management, SNMP v1/v2c/v3, RMON
Model
S6520-24S-SI
Operating Humidity
10% to 90%, non-condensing
Operating Temperature
0°C to 50°C
Packet Buffer Memory
2MB
Ports
24 x 10GbE SFP+ ports
Power Supply
Dual power slots, power supplies sold separately
Product Series
H3C S6520-SI
Quality of Service (QoS)
Advanced QoS features
Redundancy Protocols
IRF, VRRP
Security Features
ACL, RADIUS, TACACS+, IEEE 802.1X, SSH, SSL
Storage Temperature
-40°C to 70°C
Switching Capacity
Up to 480 Gbps
Type
10G Multi-rate Switch
VLAN Support
Up to 4094 VLANs
