Brand
Huawei
Compliance
RoHS, CE, FCC
Connector Type
20-pin connector
Cooling
Passive
Dimensions
240 mm x 100 mm x 30 mm
Input Voltage from Power Module
-48V DC
LED Indicators
Power status, Fault status
Model
H902PILA
Mount Type
Rack Mount
MTBF (Mean Time Between Failures)
100,000 hours
Operating Temperature
-40??C to +70??C
Output Voltage to Equipment
+12V DC
Packaging Contents
Connect Power Board, User Manual, Mounting Screws
Power Output
120W
Product Type
Connect Power Board
Protection Features
Over-current, Over-voltage, Over-temperature
Relative Humidity
5% to 95% (non-condensing)
Safety Certifications
UL, CSA, TUV
Storage Temperature
-40??C to +85??C
Warranty
2 Years
