Brand
Cisco
Bundle Components
ESP-100G, RP2, SIP40, AESK9, License
Chassis
6-slot chassis
Console Ports
1 x RJ-45 console, 1 x mini-USB console
Dimensions (HxWxD)
27.8 x 43.7 x 44.3 cm (10.95 x 17.2 x 17.4 inches)
Encryption
AES 256-bit
Management
Web-based GUI, CLI, SNMP
Maximum Throughput
100 Gbps
Memory
16GB DRAM
Model
ASR1K6R2-100-VPNK9
Network Interface Modules
Supports SIP40
Operating Temperature
0 to 40??C (32 to 104??F)
Power Consumption
Typical: 860W, Maximum: 1000W
Power Requirements
AC 90V-264V, 47-63Hz
Processor
Route Processor 2 (RP2)
Redundancy
Dual power supply for redundancy
Regulatory Compliance
FCC, UL/CSA, CE
Router Type
Aggregated Services Router
Storage Temperature
-40 to 70??C (-40 to 158??F)
VPN Support
Yes, integrated VPN services
Warranty
1 year limited hardware warranty
