Antenna Type
Internal omni-directional antennas
Brand
Aruba
Compliance
FCC, IC, CE Mark, cTUVus, CB
Dimensions
150mm x 86mm x 40mm (5.9in x 3.3in x 1.6in)
Encryption
WEP, WPA, WPA2, WPA3
Ethernet Interfaces
1x 10/100/1000BASE-T (RJ-45), 3x 10/100/1000BASE-T (RJ-45) switched
LED Indicators
1 indicator for power, status
Maximum Data Rate
867 Mbps
Maximum Transmit Power
2.4 GHz: 21 dBm, 5 GHz: 21 dBm
Model
AP-203H (RW) FIPS/TAA Unified AP
Mounting Options
Desk, wall, and ceiling
Network Management
Aruba AirWave, Aruba Central
Operating Frequency
2.4 GHz and 5 GHz
Operating Humidity
5% to 93% non-condensing
Operating Temperature
0??C to +40??C (+32??F to +104??F)
Power Supply
802.3af PoE, 12V DC power supply (optional)
Receiver Sensitivity
-94 dBm
RF Management
Adaptive Radio Management (ARM)
Security
FIPS 140-2, WPA3, Enhanced Open, WIPS
Supported Clients
Multiple device support including smartphones, laptops, and IoT devices
Wi-Fi Standards
IEEE 802.11a/b/g/n/ac
