Brand
Aruba
CPU
Dual-Core ARM
Dimensions
44 x 442 x 276 mm
Environmental Certification
FIPS, TAA
Form Factor
1U Rack Mountable
Management Interface
1 x RJ-45 Serial Console, 1 x 1000BASE-T Ethernet Management Port
Maximum APs Supported
24
Memory
2 GB DRAM
Model
JW706A
Network Ports
24 x 10/100/1000BASE-T
Operating Humidity
5% to 95% non-condensing
Operating Temperature
0??C to 40??C (32??F to 104??F)
Power Consumption
90 Watts Maximum
Power Supplies
Dual, Internal
Product Name
Aruba 7024 (RW) FIPS/TAA Branch Controller
Routing Protocols
OSPF, BGP, RIPv2
Storage
8 GB Flash
Storage Temperature
-10??C to 70??C (14??F to 158??F)
Supported Wireless Standard
802.11a/b/g/n/ac
Switching Capacity
12 Gbps
USB Ports
2 x USB 2.0
VLANs Supported
4096
